UPS ERA PLUS STRIP 1000 TOGETHER ON

UPS ERA PLUS STRIP 1000 UPS TOGETHER ON, For PC, Cash Register – AVR Stabilization, Backup time up to 20 min, USB and Software for UPS TecnoManager Win/Mac

UPS ERA PLUS STRIP 1000 TOGETHER ON. Line interactive plus technology. Dimensions 20x10x34,5 cm, weight 4,4 kg, Backup time up to 20 min. Designed for PCs, printers, telematic cash registers and pos. It has 4 schuko/italian 10A type outputs protected against blackout, overvoltages and undervoltages and 4 schuko /italian 10A type outputs protected against overvoltages and undervoltages. Equipped with LED for signaling the operating status and a USB interface for UPS control and on/off programming via the free Tecnomanager software.

Reviews

There are no reviews yet.

Be the first to review “UPS ERA PLUS STRIP 1000 TOGETHER ON”

Votre adresse e-mail ne sera pas publiée. Les champs obligatoires sont indiqués avec *

Fiche technique
CodeFGCERAPS1002SCH
TechnologyLine Interactive with stabilizer
CoolingNatural
Audible Noise< 40 dBA to 1 m
Input ConnectionsFixed cable with Schuko plug
Dimension (UPS) WxHxD20x10x34,5 cm
Dimension (with packing) WxHxD26,9x14,6x42,5 cm
Weight4,4 Kg
Max Computer Power1000VA/700W
Outlets4 UPS outputs Schuko/Italian + 4 only filtered output Schuko/Italian
InterfaceUSB Port
Input
Nominal VoltageSingle-phase 230Vac
Input Voltage Range+20%/-25%
Nominal Frequency50/60 Hz (automatic selection)
Number of phases1Ph+N
Input frequency range+/-5%
Output
Number of phases1Ph+N
Nominal voltageSingle-phase 230Vac
Frequency50/60 Hz (automatic selection)
Inverter waveformModified sinewave
Voltage regulation (Line mode)AVR (Automatic Voltage Regulation)
Voltage regulation (Battery mode)+/-5%
Battery
TypeLead acid, sealed, maintenance free
Backup time (Typical)10-70 min
Environmental specification
Working TemperatureFrom 0 to 40 °C (retcomended from 20 to 25 °C)
Humidity< 95% without condensation
Maximum Altitude3000 m
IP ProtectionIP20
CertificationsCE (Standards: Low Voltage Directive IEC EN 62040-1; EMC Directive IEC EN 62040-2; classification IEC EN 62040-3)
